The Hyundai WIA E160A CNC Turning Center combines precision, rigidity, and cost-effective performance for modern manufacturing. Its 45° slant-bed design, engineered to enhance structural stability and absorb vibration, supports powerful cutting operations while helping maintain machining accuracy. High-precision components and advanced control technology contribute to reliable performance and consistent part quality. With its compact design and efficient operation, the E160A is ideal for automotive components, industrial parts, and general precision manufacturing, delivering dependable results and excellent value for manufacturers seeking to improve productivity and profitability.
Control | Fanuc i Series controller |
Main Spindle | 6,000 RPM Belt Driven |
Main Spindle Power | Powerful 15 HP (11kW) Motor |
Main Spindle Chuck Size | 610" |
Bar Capacity | Ø1.8” (Ø45mm) |
Max Turning Diameter | Ø11” (Ø280mm) |
Max Turning Length | 11.8” (300mm)
|
Swing over bed | Ø18.9” (Ø480mm) |
Swing over carriage | Ø11.2” (Ø285mm) |
Number of Tools | 12 Position Turret |
